SHEEPDOG

TRIAD PRO™ PTT/Mic, IP68, Quick Disconnect, Acoustic Tube Earpiece
$208.00
SKU: TRIAD-PRO-M12-QD (AT)

The TRIAD PRO™ Quick Disconnect Push-To-Talk (PTT) Microphone is IP68 waterproof, built with a 3.5mm audio port, loudspeaker and durable strain reliefs. The straight 20-inch cord is ideal for simple cable management on plate carriers.

✔ Includes Earpiece
✔ Includes QD Adapter

EMPTY DOM REMOVE PROTECTOR
Availability - In Stock
RADIO MODEL:

RADIO MODEL
Quantity:
EMPTY DOM REMOVE PROTECTOR

GOVERNMENT QUOTE

×

Submit information below to receive a quote by email.

SKU: TRIAD-PRO-M12-QD (AT)
×

Thank you

Triad Pro PTT Microphone QD Triad Pro PTT Microphone QD

TRIAD PRO

The TRIAD PRO™ is a mid-sized device, slightly larger than the original TRIAD series. IP68 Waterproof. 3.5mm earpiece port. Quick Disconnect.

Triad Pro PTT Microphone QD Triad Pro PTT Microphone QD

STRAIGHT CORD

Built with a straight 20-inch cord for easy routing through vest carriers, through MOLLE or under patches.

Triad Pro PTT Microphone QD

ALLIGATOR CLIP

The strong Alligator clip is designed to stay secure to any uniform type, including MOLLE.

QD ADAPTER

Includes a 6-Pin Quick Disconnect (QD) radio adapter for simple setup and removal, using our simple "push-pull" design. QD is ideal for those who prioritize speed and efficiency.

TRIAD PRO

STRAIGHT CORD

ALLIGATOR CLIP

QD ADAPTER

IP68 Waterproof

IP68 WATERPROOF

Fully protected against dust and can withstand continuous immersion in water beyond 1 meter for approx 30 minutes.
PRODUCT

The TRIAD PRO™ Quick Disconnect Push-To-Talk (PTT) Speaker Microphone is IP68 rated and built with a 3.5mm audio port. The TRIAD PRO™ is built with an easy to locate side PTT (Push-To-Talk) and a premium direction microphone. Includes 6-Pin Quick Disconnect radio adapter. The cables are easily routed through carriers.

The TRIAD PRO™ is a mid-sized device, slightly larger than the original TRIAD series, measuring 3"x2.4"x1", and a Cord Length of 20-Inches.

✔ Includes 6-Pin Quick Disconnect Radio Adapter
✔ Includes Acoustic Tube Earpiece
✔ Built-In Loud Speaker

Features

  • Alligator Clip (Attach anywhere, including MOLLE)
  • Straight Cord for Simple Routing
  • 6-Pin Quick Disconnect
  • IP68 Rated (Water/Dust Proof)
  • Tactile Side PTT Button
  • Durable Strain Reliefs

Specifications

  • Physical:
    • IP68 rated – 1.5m submersion in water for 30 minutes
    • Operating Temperature: -4°F to 122°F (-20°C to 50°C)
    • Cable Length:  20" Straight Cord
    • Approximate Weight: 5oz (142g)
  • Microphone:
    • Sensitivity: -40dBV
    • Omni-directional Electret
    • Protected from wind and environmental elements
  • Speaker:
    • Sensitivity:  104dB SPL at 30cm
    • Impedance: 8 ohms
Connector List

Motorola (M12)
APX NEXT, APX 900, APX 1000, APX 2000, APX 3000, APX 4000, APX 4000XH, APX 5000, APX 6000, APX 6000LI, APX 6000XE, APX 7000, APX 7000XE, APX 8000, APX 8000H, APX 8000HSRX, APX 8000HXE, APX 8000XE, APX 900, XPR 6000, XPR 6100, XPR 6300, XPR 6350, XPR 6380, XPR 6500, XPR 6550, XPR 6580, XPR 7000, XPR 7000E, XPR 7300, XPR 7350, XPR 7350E, XPR 7380, XPR 7380E, XPR 7500, XPR 7550, XPR 7550E, XPR 7580, XPR 7580E, SRX2200. Not compatible with Motorola N Series radios (N70, N50 and N30). See M20 for N30/50/70 radios.

Motorola (M3)
GP900, GP9000, HT1000, JT1000, MT2000, MTS2000, MTX8000, MTX838, MTX900, MTX9000, MTX960, MTX-LS, XTS2500, XTS3000Astro, XTS3500, XTS5000, XTS3000, PR1 500, XTS1500, MX838

Motorola (M20)
APX N30, N50, N70, MXP600, R7, ION
Compatible Firmware Versions:
Motorola APX N30/N50: R35.00.00
Motorola APX N70: R05.00.00
Motorola R7: 2022.02
Motorola ION: 2022.03

Motorola (M)
All Motorola 2-Pin radios and brands utilizing a Motorola 2-Pin accessory jack.

Motorola (M14)
TLK100, TLK110, Nitro- SLN1000, SL300, SL7550,7580,7590, SL3500e, SL7550e, 7580e, 7590e

Motorola (M15)
XPR3300/3500

Harris (HR3)
XG-100P, XL-185P, XL-185Pi XL-200P, XL-200Pi, XL-150P, XL Extreme 400P

Harris (HR2)
P5300 / 5400 / 5500 Series- P5350, P5370, P5450, P5470, P5550, P5570, P7300 Series - P7370, P7350, XG-15P, XG-25P, XG-75P, XL45P, XL95P

Harris (HR1)
L3Harris: MA/Com Jaguar 700P, 700PI, P5100, P5130, P5150, P5200, P7100, P7130, P7150, P7170, P7200, P7270

HIROSE
Works with 6-pin quick disconnect (HIROSE) adapters.

Kenwood (K)
All Kenwood 2-Pin radios and brands utilizing a Kenwood 2-Pin accessory jack.

Kenwood (K1)
NX-200, NX-210, NX-210G, NX-300, NX-300G, NX-3200, NX-3300, NX-3320, NX-3400, NX-3420, NX-410, NX-5200, NX-5200-IS, NX-5300, NX-5300-IS, NX-5400, NX-5400-IS, TK-D200, TK-D300, TK-190, TK-200, TK-280, TK-290, TK-380, TK-385, TK-390, TK-410, TK-411, TK-480, TK-481, TK-2140, TK-2180, TK-2260, TK-3140, TK-3148, TK-3180, TK-3212, TK-3260, TK-4180, TK-5210, TK-5210(G), TK-5220, TK-5310, TK-5310(G), TK-5320, TK-5400, TK-5410, TK-5410D, TK-5420, VP5230, VP5330, VP5430, VP6230, VP6330, VP6430, Kenwood Viking VP5000, VP6000, and VP8000

Tait (TA)
TP7100 / 8100 series, TP9300 / 9400 series, Harris TP3300 / TP3350, TP9500 / TP9600

FAQ

Common Questions

The TRIAD PRO features a 20-inch straight cord for clean routing through gear, and a mid-sized form factor (approx. 3" x 2.4" x 1"), offering a balance between durability and low profile.

The TRIAD PRO is built for rugged environments with a reinforced housing, strain relief cabling, and a secure alligator clip that attaches to uniforms, plate carriers, or MOLLE systems. It’s designed for law enforcement, military, and tactical professionals.


Yes. The TRIAD PRO is IP68-rated, meaning it is fully protected against dust and can be submerged in water up to 1.5 meters for 30 minutes without damage.

No. The TRIAD PRO features a built-in speaker and microphone, so it can be used as a standalone unit. However, it also includes a 3.5mm earpiece port if you prefer discreet listen-only audio.

The TRIAD PRO uses a 6-pin quick disconnect system, allowing it to pair with a wide range of radio adapters. This makes it easy to swap between different radio models without replacing the entire microphone.
